Panasonic SC-ALL2 User Manual

- 24 -
This unit is compatible with several music services.
Visit the following website for the compatibility information.
www.panasonic.com/global/consumer/homeav/allseries/service
Preparation
≥ Make sure that the network is connected to the Internet.
≥ Connect a device with a compatible app installed to the same network
as this system.
1 Turn this unit on.
≥ Check that the network indicator (blue) lights up.
– If the network indicator is blinking in blue and red, wait until the blinking
stops.
2 Start the app, and select a song to playback.
∫ Using Spotify
≥ You will need Spotify Premium. For details, visit the following website.
www.spotify.com/connect/
After step 2
3 Select the square image of the song’s cover art in the bottom
left of the playback screen.
4 From “ ”, select this system as the output speakers.
≥ To enjoy synchronised sound from the multiple speakers powered by
AllPlay, you need to group the speakers using the app “Panasonic Music
Streaming”. (l 21)
Streaming online music

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
