Panasonic SC-ALL2 User Manual

- 49 -
Pairing cannot be done.
≥ Check the Bluetooth
®
device condition.
The device cannot be connected.
≥ The pairing of the device was unsuccessful or the registration has been
replaced. Try pairing the device again. (l 30)
≥ This system might be connected to a different device. Disconnect the
other device and try pairing the device again.
The device is connected but audio cannot be heard through this
system.
≥ For some Bluetooth
®
devices, you have to set the audio output to
“SC-ALL2” manually. Read the operating instructions for the device for
details.
Connection is interrupted.
Sound is interrupted/sound skips/there is a lot of noise.
≥ Remove any obstacle between this system and the device.
≥ Other devices that use the 2.4 GHz frequency band (wireless router,
microwaves, cordless phones, etc.) are interfering. Bring the Bluetooth
®
device closer to this system and distance it from the other devices.
≥ Select “Ll: 1” for stable communication. (l 33)
If the above does not fix the problem, you may be able to fix the problem
by reconnecting this unit and the Bluetooth
®
device. (l 31)
Bluetooth
®

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
