Panasonic SC-HC40PC - Page 126

126
42 RMQX1023-K DOCKING COVER 1
43 RMQX1024-K DOCKING HOLDER 1
44 RDG0546 BELT PULLEY 1
45 RDGX0050 MIDDLE GEAR 1
46 RDGX0051 DRIVE GEAR 1
47 RDVX0001 BELT 1
48 RMKX0159-1 GEAR FIXTURE 1
49 RMKX0160-1 GEAR BASE 1
50 RXQ1690 MOTOR UNIT 1
51 RYPX1029H-S TOP ORNAMENT
UNIT
1
51-1 RGUX1015B2SJ POWER BUTTON 1
51-2 RGUX1019-1SJ iPod PLAY BUTTON 1
51-3 RGUX1012A2SJ CD EJECT BUTTON 1
52 VHD1224-1 SCREW 11
53 L6FAYYYH0122 FAN UNIT 1
54 RGLX1004-Q LIGHTING BAR 1
55 RYKX1026J-K REAR CABINET
UNIT
1
57 RGQX1005 FL FILTER 1
58 RMFX1024 ACOUSTIC
ABSORBER
4
59 RMQX0361 EVA PACKING PAS-
SIVE REAR
2
60 RSCX1030 BRACKET R 2
61 RHDX301002 SCREW 7
62 XSN2+4FJ SCREW 2
63 XTB3+10JFJK SCREW 38
64 XTB3+8JFJ SCREW 5
65 XTW3+16TFJK SCREW 1
66 RMC0780A iPod SPRING
PLATE
1
67 RSCX1034 iPhone SHIELD 1
68 RMQX0358 EVA PACKING
FRAME A
2
69 RMQX0357 EVA PACKING
FRAME
4
70 RMQX1048 EPT SEALER BAR-
RIER
2
71 RGLX1003-Q LIGHTING PIECE 1
74 RMFX1023 HIMELON (BUTTON) 2
75 RMFX1038 HIMELON (SCREW) 2
76 RMFX1026 HIMELON (SP NET
SMPS INSULATOR
C)
4
77 RMFX1027 HIMELON (BTM
ORNAMENT, BOSS
REAR CABINET)
5
78 RMFX1028 HIMELON (SMPS
SHIELD)
4
79 REEX1132-J 22P FFC (USB-
VERTICAL MAIN)
1
80 REEX1133-J 12P FFC (BLUE-
TOOTH-VERTICAL
MAIN)
1
81 RGQX0053-K USB PANEL 1
82 RGQX1001A-K SD LID 1
83 RGQX1003-K SD HOLDER 1
84 RMCX1002 CRADLE LID
SPRING
1
85 RMGX0033 CUSHION RUBBER 1
86 RSCX0211 USB SHIELD PLATE 1
90 RHD14129 SCREW 3
91 RMFX1037 HIMELON (SP NET
FRAME R)
1
92 RMFX1034 PC SHEET (BUT-
TON PCB)
1
93 RMQX1057 HIMELON (REAR
CABINET )
2
SPEAKERS
SP1 EAS65P144B FRONT SPEAKER 1
SP2 EAS65P144B FRONT SPEAKER 1
SP3 EAS8DY01B PASSIVE RADIATOR 1
SP4 EAS8DY01B PASSIVE RADIATOR 1
SP5 EAS8DY01B PASSIVE RADIATOR 1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
SP6 EAS8DY01B PASSIVE RADIATOR 1
TRAVERSE DECK
401 RAE0165T-V TRAVERSE UNIT
ASS'Y
1
402 RMS0757-1 FIXED PIN 4
403 XTN2+6GFJ SCREW 3
404 RME0109-1 FLOATING SPRING 4
405 RMG0730-G FLOATING RUBBER 4
406 RMR1395A-X MIDDLE CHASSIS 1
407 RMR1396-K TRAVERSE COVER 1
PACKING MATERI-
ALS
P1 RPGX3390 PACKING CASE 1
P2 RPNX1022-1 POLYFOAM 1
P3 RPFX0262-1 MIRAMAT SHEET 1
ACCESSORIES
A1 N2QAYB000523 REMOTE CONTROL 1
A1-1 RKK-PT470EBK R/C BATTERY
COVER
1
A2 K2CB2CB00021 AC CORD 1
A3 RQTX1217-C OI BOOK (En/Cf) 1
A4 N1DYYYY00010 AM LOOP ANTENNA 1
A5 RSAX0002 FM INDOOR
ANTENNA
1
A6 RFAX1020 SCREW ACCESSORY 1
A7 RFAX1021 WALL BRACKET
ACCESSORY
1
Safety Ref. No. Part No. Part Name &
Description
Qty Remarks
