Panasonic SC-HC40PC User Manual

83
11.6. PANEL P.C.B.
11.7. BUTTON P.C.B.
11.8. TUNER P.C.B.
11.9. IR P.C.B.
REF NO.
MODE 1234567891011121314151617181920
CD PLAY
0000
2.3 3.3 0 0 1.5
0
0 0 3.3 -26.4 -26.4 -24.2 -19.0 -24.0 -15.3 -26.4
STANDBY
0000
2.3 3.3 0 0 1.5
0
0 0 3.3 -26.4 -26.4 -24.1 -15.2 -21.9 -13.0 -26.4
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -26.4 -26.4 -19.7 -19.7 -26.4 -24.2 -26.4 -19.7 -17.9 -26.9 -18.0 -25.2 -24.9 -24.5 -24.4 -24.4 -24.4 -24.4 -24.4 -24.4
STANDBY -26.4 -26.4 -13.1 -19.7 -26.4 -24.2 -26.4 -15.3 -19.7 -26.8 -15.4 -25.2 -24.8 -24.4 -24.4 -24.4 -24.4 -24.4 -24.4 -24.4
REF NO.
MODE 41 42 43 44
CD PLAY
-24.4 -24.4 3.3 0
STANDBY
-24.4 -24.4 3.3 0
SC-HC40PC PANEL P.C.B.
IC6801
IC6801
IC6801
REF NO.
MODE E C B
CD PLAY
00.93.2
STANDBY
00.93.2
SC-HC40PC BUTTON P.C.B.
Q900
REF NO.
MODE 1234567891011121314151617181920
CD PLAY
03.003.0
00001.2
0
3.3 0 1.4 0.3 0.3 0.3 1.2 0 0 0
STANDBY
03.003.0
00001.0
0
3.3 0 1.4 0.3 0.3 0.3 1.2 0 0 0
SC-HC40PC TUNER P.C.B.
IC52
REF NO.
MODE 12345678
CD PLAY
3.3 3.3 3.2 0
3.2 3.3 3.3 6.5
STANDBY
3.3 3.3 3.2 0
3.2 3.3 3.3 6.5
REF NO.
MODE E C B
CD PLAY 0 0 0
STANDBY 0 0 3.3
SC-HC40PC IR P.C.B.
IC320
Q320
