Panasonic TH-37PG9W - 16 Mechanical Replacement Parts List

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
1 EAS12S10A SPEAKER 1
1 EAS12S10A SPEAKER 1
J0KF00000038 CORE 1 (TH-42PG9W)
2 K2AHYH000003 AC INLET 1
3 K2CK3DH00029 AC CORD(OBLIQUE
FLAT BLADE)
1
3 K2CN3DH00006 AC CORD(ROUND PIN) 1
3 K2CT3DH00018 AC
CORD(RECTANGULAR
BLADE)
1
4 MD37S09A1J PLASMA DISPLAY
PANEL
1 (TH-37PG9W)
4 MD42S09A1J PLASMA DISPLAY
PANEL
1 (TH-42PG9W)
5 TBMA185 PANASONIC BADGE 1
6 TBXA48702 POWER BUTTON 1
7 TBXA48803 CONTROL BOTTON 1
8 TESA274 LEAF SPRING 1
9 TESD078 BUTTON SPRING 1
THEA068N SCREW 4
THEL0239 SCREW 2
THEL0239 SCREW 12
THEL027N SCREW 4
THEL0429 SCREW 14
THTD0179 STEP SCREW(P-
SPACER)
4
THTF011N SCREW 3
THTF011N SCREW 16
THTF011N SCREW 22
THTF011N SCREW 22
10 TKGA5275 FRONT GLASS 1 (TH-42PG9W)
10 TKGA5277 FRONT GLASS 1 (TH-37PG9W)
11 TKKC5246 LED PANEL 1
12 TKKL5266 COVER 2
13 TKPB01102 DOOR 1
14 TKRA51701 REAR COVER HANDLE 2
15 TKKL5231 M8 SPACER CAP 4
16 TMZX5058 STAND BRACKET 2
17 TMKG658 SPONGE(TKG/LEFT/RI
GHT)
2 (TH-37PG9W)
17 TMKG660 SPONGE(FRONT GLASS
V)
2 (TH-42PG9W)
18 TMKG657-1 SPONGE(UPPER/B
OTTOM)
2 (TH-37PG9W)
18 TMKG659-1 SPONGE(UPPER/B
OTTOM)
2 (TH-42PG9W)
TMM14490 CLAMPER 2
TMM14490 CLAMPER 1
TMM15414-2 CLAMPER 1
TMM16473-1 CLAMPER 1
TMM17434-2 CLAMPER 1
TMM17499 CLAMPER 1
TMM25401 CLAMPER 1
TMM25401 CLAMPER 3
TMM25401 CLAMPER 3
TMM6496-1 CLAMPER 1 (TH-42PG9W)
TMM7464-2 CLAMPER 4
TMM7468-1 CLAMPER 1
TMMD010 CLAMPER 1
TMME061 CLAMPER 2
TMME061 CLAMPER 2
TMME061 CLAMPER 1
TMME185 CLAMPER 2
19 TMME187 CLAMPER 2
TMME190 CLAMPER 1
TMME217 CLAMPER 1
TMME226 AC CORD CLAMPER 2
TMME228 CLAMPER 2
TMMX037 CLAMPER 1
20 TPCB97501 CARTON BOX TOP 1 (TH-37PG9W)
20 TPCB92505 CARTON BOX TOP 1 (TH-42PG9W)
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
21 TPCB97601 CARTON BOX BOTTOM 1 (TH-37PG9W)
21 TPCB92601 CARTON BOX BOTTOM 1 (TH-42PG9W)
22 TPDA1379 CUSHION TOP 1
23 TPDA1360 CUSHION BOTTOM 1
24 TPDF1671 TOP PAD 1 (TH-37PG9W)
24 TPDF1582 TOP PAD 1 (TH-42PG9W)
25 TPD169487 JOINT 4
26 TPDF0737 PAPER BOX 1
27 TPEH210 PROTECT COVER 1
29 TQBC2112 INSTRUCTION
BOOK(ENGLISH)
1
29 TQBC2119 INSTRUCTION
BOOK(ARABIAN)
1
30 TSXL513 CABLE(D31-C11/D32-
C21)
2
31 TSXL519 CABLE(C12-C22) 1
32 TSXL543 CABLE(DA2-D3) 1
33 TXFKE01ZPTW ESCUTCHEON ASSY 1 (TH-37PG9W)
33 TXFKE01ZQTW ESCUTCHEON ASSY 1 (TH-42PG9W)
34 TTUA1406 REAR COVER 1 (TH-37PG9W)
34 TTUA1405 REAR COVER 1 (TH-42PG9W)
35 TMMX133 M8-SPACER 4
TXJ/J7ZQTU SPEAKER REED 1
TXJ/SPZQTU SPEAKER LEAD 1
XTB4+12GFJ SCREW 6
XTB4+12GFJ SCREW 45
XTB4+12GFJK SCREW 8
XTB4+16GFJ SCREW 2
XTV3+10JFJ SCREW 2
XTW3+10TFJ SCREW 3
XYN3+F8FJ SCREW 13
XYN3+F8FJ SCREW 2
XYN3+F8FJ SCREW 2
XYN3+J12FJ SCREW 13
XYN3+J12FJ SCREW 12
XYN4+E8FJ SCREW 1
XYN4+F10FJ SCREW 6
XYN4+F10FJK SCREW 6
XYN4+F30FJK SCREW (BC TOP6
SIDE6: AL
6
XYN5+C15FJ SCREW 8
XZBT6506 POLY BAG 1
16 Mechanical Replacement Parts List
135
TH-37PG9W / TH-42PG9W
