Panasonic TH-37PG9W - Page 146

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
Q404 B1BCCF000022 TRANSISTOR 1
Q406 B1DEHQ000007 TRANSISTOR 1
Q407 B1HFCFA00021 TRANSISTOR 1
Q408,09 B1DHCD000034 TRANSISTOR 2
Q412,13 B1DEGQ000070 TRANSISTOR 2
Q418 2SD1819A TRANSISTOR 1
Q420-22 2SD1819A TRANSISTOR 3
Q434 B1CEJQ000003 ÇeÇdÇs 1
Q501,02 2SD1820A TRANSISTOR 2
Q505 B1CEJQ000002 ÇeÇdÇs 1
Q507 B1DAGQ000013 TRANSISTOR 1
Q508 B1HBCFA00033 TRANSISTOR 1
Q509 B1HDCEA00001 TRANSISTOR 1
Q510 B1DHBD000005 TRANSISTOR 1
Q512 B1CBGD000001 FET 1
Q517 B1HBCFA00033 TRANSISTOR 1
Q520 B1HBCFA00033 TRANSISTOR 1
Q521 B1CBGD000001 FET 1
Q524 B1CFGF000008 TRANSISTOR 1
Q525 B1CBGD000001 FET 1
Q527 B1CERL000005 TRANSISTOR 1
Q530 2SD1819A TRANSISTOR 1
Q535 2SD1819A TRANSISTOR 1
Q537 B1DFDD000019 TRANSISTOR 1
Q538 B1CBGD000001 FET 1
Q540 B1DHCD000034 TRANSISTOR 1
Q541 B1CBGD000001 FET 1
Q551 B1CBGD000001 FET 1
Q553 2SD1819A TRANSISTOR 1
Q554 B1DHCD000034 TRANSISTOR 1
Q555,56 B1DFGD000045 TRANSISTOR 2
Q557-59 2SD1819A TRANSISTOR 3
Q561 2SD1819A TRANSISTOR 1
Q563 B1CFGF000008 TRANSISTOR 1
Q564,65 2SB1218ARL TRANSISTOR 2
Q566 2SD1819A TRANSISTOR 1
Q568 B1CHGD000006 TRANSISTOR 1
Q569 B1CBGD000001 FET 1
Q2300 B1BBCF000028 TRANSISTOR 1
Q2331 B1BBCF000028 TRANSISTOR 1
Q2372 2SD601A TRANSISTOR 1
Q2510,1
1
2SD601A TRANSISTOR 2
Q2513 2SD601A TRANSISTOR 1
Q3001 2SB709A TRANSISTOR 1
Q3002 2SD601A TRANSISTOR 1
Q3004 2SD601A TRANSISTOR 1
Q3531,3
2
2SD601A TRANSISTOR 2
Q4701 B1CBHD000002 FET 1
Q4702-
07
2SD601A TRANSISTOR 6
Q4709,1
0
2SD601A TRANSISTOR 2
Q4712-
14
2SD601A TRANSISTOR 3
Q4801 B1CBHD000002 FET 1
Q4802,0
3
2SD601A TRANSISTOR 2
Q4901-
03
B1MBEDA00015 TRANSISTOR 3
Q4961,6
2
2SD601A TRANSISTOR 2
Q6001-
03
2PG0010000RP TRANSISTOR 3
Q6021-
23
2PG0010000RP TRANSISTOR 3
Q6041,4
2
2PG0010000RP TRANSISTOR 2
Q6051 2PG0010000RP TRANSISTOR 1
Q6101,0
2
B1DFKM000002 TRANSISTOR 2
Q6111 2SK326800L FET 1
Q6112 B1DFKM000002 TRANSISTOR 1
Q6141 B1ABNF000006 TRANSISTOR 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
Q6142 B1ADNF000006 TRANSISTOR 1
Q6146 B1ABNF000006 TRANSISTOR 1
Q6147 B1ADNF000006 TRANSISTOR 1
Q6221 2SD1263A TRANSISTOR 1
Q6222 2SC1473A TRANSISTOR 1
Q6251 2SD601A TRANSISTOR 1
Q6401-
03
2PG0010000RP TRANSISTOR 3
Q6421-
23
2PG0020000RP TRANSISTOR 3
Q6441,4
2
2PG0010000RP TRANSISTOR 2
Q6451 2PG0020000RP TRANSISTOR 1
Q6471 B1CHGD000006 TRANSISTOR 1
Q6511 B1ABNF000006 TRANSISTOR 1
Q6512 B1ADNF000006 TRANSISTOR 1
Q6516 B1ABNF000006 TRANSISTOR 1
Q6517 B1ADNF000006 TRANSISTOR 1
Q6581 2SD601A TRANSISTOR 1
Q6601 B1DFES000003 TRANSISTOR 1
Q6602 2SD601A TRANSISTOR 1
Q6621,2
2
2SK399500L FET 2
Q6642-
44
2SK399500L FET 3
Q6646-
48
2SK399500L FET 3
Q6661 B1DEET000002 TRANSISTOR 1
Q6662 2SD601A TRANSISTOR 1
Q6663 2SD2185 TRANSISTOR 1
Q6671 B1DFES000003 TRANSISTOR 1
Q6680 B1ADNF000006 TRANSISTOR 1
Q6681,8
2
2SK389500L FET 2
Q6691 2SK620 FET 1
Q6742,4
3
2SD601A TRANSISTOR 2
Q6744 2SK620 FET 1
Q6762 B1ADNF000006 TRANSISTOR 1
Q6781 B1ABNF000006 TRANSISTOR 1
Q6782 B1ADNF000006 TRANSISTOR 1
Q6791 2SD601A TRANSISTOR 1
Q6801 B1BAEJ000014 TRANSISTOR 1
Q6802 2SB0709A TRANSISTOR 1
Q6803 2SD814A TRANSISTOR 1
Q6821 2SD1263A TRANSISTOR 1
Q6822 2SC3063 TRANSISTOR 1
Q6824 2SD601A TRANSISTOR 1
Q6841 2SD1263A TRANSISTOR 1
Q6842 2SC1473A TRANSISTOR 1
Q6921 2SK620 FET 1
Q8002 2SD601A TRANSISTOR 1
Q8010 2SD601A TRANSISTOR 1
Q8011 2SB709A TRANSISTOR 1
Q8012 2SD601A TRANSISTOR 1
Q8013 2SB709A TRANSISTOR 1
Q8019 2SD601A TRANSISTOR 1
Q8181-
84
B1CBHD000002 FET 4
Q8200-
02
2SD601A TRANSISTOR 3
Q9010 2SD601A TRANSISTOR 1
Q9044 2SD601A TRANSISTOR 1
Q9046 2SD601A TRANSISTOR 1
Q9050-
54
2SD601A TRANSISTOR 5
Q9055-
58
B1CBHD000002 FET 4
Q9300-
02
2SD601A TRANSISTOR 3
Q9800,0
1
B1MBEDA00015 TRANSISTOR 2
Q9803 B1MBEDA00015 TRANSISTOR 1
Q9805,0
6
2SD601A TRANSISTOR 2
146
TH-37PG9W / TH-42PG9W
