Panasonic WV-SP300 Series

44
 • When"8192kbps*"or"Unlimited*"isselected,the
number of users who can access H.264 images will
belimitedto"1".(Onlyasingleusercanaccess
H.264 images.)
 • Itisimpossibletoselect"Unlimited*"forboth
"H.264(1)" and "H.264(2)".
*1
SP306
SP305
SF336
SF335
*2
SP302
SF332
[Image quality]
Select the image quality of H.264 images from the fol-
lowing.
Fine(Image quality priority)/ Normal/ Low(Motion prior-
ity)
Default: Normal
Note:
 • When"Constantbitrate"isselectedfor
"Transmission priority", this setting is available.
[Refresh interval]
Select an interval (I-frame interval; 0.2 - 5 seconds) to
refresh the displayed H.264 images.
If using under a network environment with frequent
error occurrences, shorten the refresh interval for H.264
to diminish image distortions. However, the refresh
interval may be longer than the set value.
0.2s/ 0.33s/ 0.5s/ 1s/ 2s/ 3s/ 4s/ 5s
Default: 3s
[Transmission type]
Select a MPEG-4 transmission type from the following.
Unicast port (AUTO): Up to 14 users can access a sin-
gle camera concurrently. "Unicast port1(Image)" and
"Unicast port2 (Audio)" will automatically be
selected when transmitting images and audio from
thecamera.Whenitisunnecessarytofixtheport
number for H.264 image transmission such as when
using in a particular LAN environment, it is recom-
mendedtoselect"Unicastport(AUTO)".
Unicast port (MANUAL): Up to 14 users can access a
single camera concurrently. It is necessary to select
"Unicast port1(Image)" and "Unicast port2 (Audio)"
manually to transmit images and audio from the
camera.
  Itispossibletofixtheportnumberoftherouter
used for H.264 image transmission via the Internet
by setting "Unicast port (MANUAL)" (☞ page 80).
Refer to the operating instructions of the router in
use.
Multicast: Unlimited number of users can access a sin-
gle camera concurrently. Complete the entry field of
"Multicast address", "Multicast port" and "Multicast
TTL/HOPLimit"whentransmittingH.264images
with multicast.
* Refer to page 7 for further information about the
maximumconcurrentaccessnumber.
Default:Unicastport(AUTO)
[Unicast port1(Image)]*
3
Enter the unicast port number (used to transmit images
from the camera).
Available port number: 1024-50000(Onlyevennum-
bers are available.)
Default: H.264(1) 32004
H.264(2) 32014
[Unicast port2(Audio)]*
3
Enter the unicast port number (used to transmit audio
from the camera).
Available port number: 1024-50000(Onlyevennum-
bers are available.)
Default: H.264(1) 33004
H.264(2) 33014
[Multicast address]*
4
Enter the multicast IP address.
Images and audio will be transmitted to the designated
IP address.
Available IPv4 address: 224.0.0.0 - 239.255.255.255
Available IPv6 address: Multicast address starting
with "FF"
Default: H.264(1): 239.192.0.20
H.264(2): 239.192.0.21
Note:
 • EnteramulticastIPaddressaftercheckingavailable
multicast address.
[Multicast port]*
4
Enter the multicast port number (used to transmit
images from the camera).
Available port number: 1024-50000(Onlyevennum-
bers are available.)
Default: 37004
Note:
 • Whenaudioistransmittedfromthecamera,theport
number to be used will be the multicast port num-
ber plus "1000".
