[Multicast TTL/HOPLimit]*
4
EnterthemulticastTTL/HOPLimitvalue.
Available value: 1-254
Default: 16
Important:
 • WhentransmittinganH.264imageviaanetwork,
the transmitted image sometimes may not be dis-
playeddependingonthesettingsofaproxyserver
or a firewall. In this case, refer to the network
administrator.
 • Whentwoormorenetworkinterfacecardsare
installed on the PC in use, the network interface
card(s) not used for receiving images should be
invalidated when displaying images using the multi-
cast port.
*3 It is necessary to designate the unicast port number
when "Unicast port (MANUAL)" is selected for
"Transmission type".
*4 It is necessary to designate the multicast IP address
when "Multicast" is selected for "Transmission
type".
