SMARTZONE UPS USER MANUAL
Appendix C: Bulk Management of PDUs
A dedicated G5 Upgrade Tool (GUT) is included with every firmware release. This
utility enables a user to bulk manage PDUs. This utility features Firmware Upgrading,
Configuration Replication (common parameters) and management of uncommon
parameters (.csv) file. Requires Windows OS.
G5 Upgrade Tool (GUT)
1. Firmware Upgrade
a. Insert IP address or IP address range in the Scan Network Tab
b. Insert admin credentials
c. Click ‘Start Upgrade’
Figure 92: G5 Upgrade Tool Interface
Note: Simplify firmware upgrade from 2.x to 3.x using this utility down to a
single click.
2. Configuration Replication of Common Parameters
a. Pre-set the common parameters (e.g. thresholds, rack access control,
etc..) via the WebGUI and download configuration (conf.ini) from the
System Management menu.
