SMARTZONE UPS USER MANUAL

146

Command

Description

Example

PDU UNIT 1 power

Feature

voltage: 0V

current : 0.0A

active power: 0W

apparent power: 0W

power factor: 0.00

energy: 0.000kWh

pwr phase <idx>

Query specified phase’s

electric information.

Panduit> pwr phase 1

SUCCESS

PDU PHASE 1 power

Feature

voltage: 0V

current : 0.0A

active power: 0W

apparent power: 0W

power factor: 0.00

energy: 0.000kWh

pwr cb <idx> Query specified circuit

breaker’s

Electric information.

Panduit> pwr cb 1

SUCCESS

PDU CB 1 power Feature

voltage: 0V

current : 0.0A

active power: 0W

apparent power: 0W

power factor: 0.00

energy: 0.000kWh

pwr outlet <idx>

Query specified outlet’s

electric information.

Panduit> pwr outlet 1

SUCCESS

PDU OUTLET 1 power

Feature

voltage: 0V

current : 0.0A
