Parker AC10 series Quick Start Guide

The AC10 has numerous function parameters that the user can modify to effect different
modes of operation. The user should be aware that if they set password valid (F107=1), the
password must be entered rst.
Parameter Setting
Menu Structure
Menu and Parameters - IP20 Units 3-2
O
I
M
E
∆
∆
E
M
E
M
or
∆
∆
or
∆
∆

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
