Parker AC10 series Quick Start Guide

5-1 Troubleshooting
Minimum required function code settings to run the drive and protect the motor.
Function
Code
Function Denition Setting Range Mfr's Value Change
F106 Control Mode 0: Sensorless vector control
(SVC);
1: Reserved;
2: VVVF
3: Vector control 1
6: PMSM sensorless vector
control
2 X
F111 Max Frequency (Hz) F113-590.0Hz 50.00 √
F112 Min Frequency (Hz) 0.00Hz-F113 0.50 √
F114 1st Acceleration Time (S) 0.1-3000 subject to
inverter
model
√
F115 1st Deceleration Time (S) 0.1-3000 √
F118 Base Frequency (Hz) 15.00-590.0 50.00 X
F801 Rated Motor Power 0.2-1000kW oX
F802 Rated Motor Voltage 1-440V oX
F803 Rated Motor Current 0.1-6500A oX
F804 Number of Motor Poles 2-100 4 oX
F805 Base Motor RPM 1-30000 oX
F800 Motor’s Parameters Selection Setting range:
0: Invalid;
1: Rotating tuning.;
2: Stationary tuning
0 X
F200 Source of start command 0: Keypad command;
1: Terminal command;
2: Keypad+Terminal;
3:MODBUS;
4: Keypad+Terminal+MODBUS
4 X
F201 Source of stop command 0: Keypad command;
1: Terminal command;
2: Keypad+Terminal;
3:MODBUS;
4: Keypad+Terminal+MODBUS
4 X
F203 Main frequency source (X) 0: Digital setting memory;
1: External analog AI1;
2: External analog AI2;
3: Reserved;
4: Stage speed control;
5: No memory by digital setting;
6-8: Reserved;
9: PID output;
10: MODBUS
0 X

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
