2-1 Product Overview
For Further Safety or Legal Questions, please contact:
Parker Hannin - Drives Business Unit
9225 Forsyth Park Dr
Charlotte, NC 28273 USA
Tel: 704.588.3246
Fax: 704.588.4806
Info.us.ssd@parker.com
www.parker.com/ssdusa
www.parker.com/ssdusa/ac10
Before You Start
This document covers the steps necessary for a basic start up of the AC10 drive. Drive start
ups should be performed by competent electrical technicians who are familiar with AC drives
and their applications. For detailed installation, safety and applications refer to the Product
Manual.
Ensure that all local electric codes are met while installing the drive. Check that all live parts
are covered to protect against electric shock and that unexpected rotation of the motor will not
result in bodily harm or injury.
This document expects that the drive is already installed in its intended location and that all
relevant installation procedures have been followed.
About This QuickStart Guide
This QuickStart will:
• Familiarize you with the terminals and operation of the unit.
• Provide basic installation details and a quick set-up procedure.
• Show you how to Autotune the drive and start the motor.
This QuickStart assumes that:
• You are a competent technician with experience of installing this type of equipment.
• You are familiar with the relevant standards and Local Electric Codes (which take
precedence).
• You have read and understood the Safety Information provided at the front of this QuickStart.
• You realize that this guide contains only basic information and that you may need to refer to
the AC10 Product Manual to complete your installation.
