Parker AC10 series Quick Start Guide

AC10 - IP66 Models
1 2 3 4 5 6 7
Order example 10 G - 1 1 - 0015 - B N
1
Product Family
16 AC10 VFD - IP66
2
Industry
G General Purpose
3
Voltage
1 230V Single Phase
3 230V Three Phase
4 480V Three Phase
4, 5
Frame Size, Rated Current
230V Supply
1-0025 0.5 HP/0.4kW
1-0045 1 HP/0.75kW
1-0070 2 HP/1.5kW
1-0100 3 HP/2.2kW
480V Supply
1-0020 1 HP/0.75kW
1-0040 2 HP/1.5kW
1-0065 3 HP/2.2kW
1-0090 5 HP/4.0kW
2-0120 7.5 HP/5.5kW
2-0170 10 HP/7.5kW
3-0230 15 HP/11kW
3-0320 20 HP/15kW
4-0380 25 HP/18.5 kW *
4-0440 30 HP/22 kW *
4-0600 40 HP/30 kW *
5-0750 50 HP/37 kW *
5-0900 60 HP/45 kW *
5-1100 75 HP/55 kW *
6-1500 100 HP/75 kW *
6-1800 125 HP/90 kW *
6
Braking Module
B Braking Module Installed
7
EMC Filter
N No Filter Installed
F C3 EMC Filter Installed
Understanding the Product Code 2-4
* Not UL listed

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
