Parker Hannifin S.p.A. - S.B.C. Division HPD N User’s Manual
98
15. Appendix L: EC4
15.1. Product description
EC-4 is an expansion board for HPD-series converters which significantly improves performance.
Basically, the code EC-4 identifies a hardware product. To use the EC-4, you need to install the
software required.
15.2. Main characteristics
The main characteristics of the EC-4 are shown in the table below:
Format Europe 1 measurements 100 x 160 mm
Degree of protection IP 00
Field bus Profibus-DP
CAN bus
RS-422
Up to 12 Mb
DeviceNet
SBCCan
ModBus for operator panel
Feedback used for the
position loop
Resolver (directly via HPD)
Incremental encoder 5 V RS - 422
SSI absolute encoder
Hyperface absolute encoder
Power supply for auxiliary
encoders
programmable voltage 5V - 8V - 12V - 15V
250mA protected.
Digital inputs 8 PNP-type
Digital outputs 8 PNP-type 100mA with short-circuit protection
ATTENTION !
EC-4 is only for drive
HPD x N EO
EC-4 can only be installed on drives with a certain software version or higher
