Parker HPD2N

Parker Hannifin S.p.A. - S.B.C. Division HPD N User’s Manual
101
15.5. EC-4 installation
ATTENTION
HIGH VOLTAGE
Before installing the EC-4 board, make surue that no wires are connected to the HPD converter.
Remove the lower panel
Insert the EC-4 board
Screw the EC-4 panel in to the body of the HPD
EC-4
