18. Digital I/O
The Digital I/O connector is a 25-pin male connector
DIGITAL I/O CONNECTOR
N. Pin Signal Description
1 DIN-0 DIGITAL INPUT 0
2 DIN-1 DIGITAL INPUT 1
3 DIN-2 DIGITAL INPUT 2
4 DIN-3 DIGITAL INPUT 3
5 DIN-4 DIGITAL INPUT 4
6 DIN-5 DIGITAL INPUT 5
7 DIN-6 DIGITAL INPUT 6
8 DIN-7 DIGITAL INPUT 7
9 +24Vin COMMON OUT
10 +24Vin COMMON OUT
11 +24Vin COMMON OUT
12 +24Vin COMMON OUT
13 +24Vin COMMON OUT
14 DOUT-0 DIGITAL OUTPUT 0
15 DOUT-1 DIGITAL OUTPUT 1
16 DOUT-2 DIGITAL OUTPUT 2
17 DOUT-3 DIGITAL OUTPUT 3
18 DOUT-4 DIGITAL OUTPUT 4
19 DOUT-5 DIGITAL OUTPUT 5
20 DOUT-6 DIGITAL OUTPUT 6
21 DOUT-7 DIGITAL OUTPUT 7
22 0V COMMON IN
23 0V COMMON IN
24 0V COMMON IN
25 0V COMMON IN
It uses digital PNP-type inputs. The characteristics common to all inputs are as follows:
DIGITAL INPUTS
Impedence input 6K Ohm
VH 15...30 V
VL 0...3 V
