Parker HPD2N

Parker Hannifin S.p.A. - S.B.C. Division HPD N User’s Manual
110
21.2. Electronic cam
Min
Max
Min
Max
0 90 180 270 360
0
90
180
270
SBC Driver + EC4 expansion board
SBC Motor
Slave
Master
Dispaly
 Homing function

Electronic cam which can be stored on the EC-4 board

Hold function to disengage and reengage the cam at a given master position

An external device can be connected using Profibus DB, DeviceNet, or RS-422 serial interface
in order change cam points in real time.
