Parker HPD2N

Parker Hannifin S.p.A. - S.B.C. Division HPD N User’s Manual
90
7. Appendix B: hardware characteristics
digital input
input impedance 7k ohm
VH 15..30 V
VL 0..3 V
digital output
type PNP open
collector
VH using internal supply 20..26 V
IO for single output 100 mA
IT current for all outputs using internal
supply
200 mA
IT current for all outputs using ext. supply
+24 VIN
500 mA
VSW max. voltage between out 6 A and
out 6 B
110 V~
ISW max. current trough out 6 A and out
6 B
600 mA
analogue reference
type differential
impedance 20 Kohm
range ± 10 V
CMMR > 60 dB
resolution 15 bits
aux. analogue input
type differential
impedance 250 Kohm
range ± 10 V
CMMR > 40 dB
resolution 10 bits
analogue output
type single ended
IO max. 1.5 mA
range ± 10 V
resolution 8 bits
