Parker Hannifin S.p.A. - S.B.C. Division HPD N User’s Manual
102
16. Profibus-DP connector
The Profibus-DP connector is a 9-pin female connector.
PROFIBUS-DP CONNECTOR
N. Pin Signal Description
1 n.c.
2 n.c.
3 RxD / TxD – P Line of communication +
4 CNTR – P Controll signal for ripetitor
5 DGND Ground
6 VP Terminal supply
7 n.c.
8 RxD / TxD – N Line of communication –
9 n.c.
The Profibus-DP interface is optional, and must therefore be expressly requested when ordering the
EC-4 board.
The Profibus interface implemented is based on the ASIC LSPM2. The EC-4 is seen by the profibus
master as a remote I/O module with 16 inputs and 16 outputs. Obviously, the I/Os are virtual.
Interpretation of the meaning of the I/Os will be defined by the program installed on the EC-4
board.
The configuration file SBC0EC4.GSD is provided to configure the EC-4 as a slave Profibus-DP.
