Hi Amp LOOP – Hi Amp LOOP –
To be used where NO RCD is present Test lead connection
5. When the measurement is complete, the impedance of L-PE and PFC (lf) value appear on
the screen
Hi Amp LOOP – Measurement finished
6. Press TEST button if re-test is necessary
If at least one of the symbols , , appears, or if the
voltage exceeds 260V, the measurement will not take place.
-73-
