PeakTech 2755 User Manual

When the line conductors are connected in the correct sequence “1 2 3” will appear as shown
above. However, connected in the wrong sequence, you will get “2 1 3” on the display:
Phase Sequence – When connected in counter-clockwise manner
5.2.9. Voltage/Phase Function Menu Operation
Main Display Menu Display
F1 Button
Pop-up and shutdown RCD menu
F2 Button
None
F3 Button
None
F4 Button
None
▲Up Button
Up menu to select the current active sub-options.
▼Down Button
Down menu to select the current active sub-options.
Enter Button
Confirm the user select mode.
-82-
