5.2.6 RCD Function Menu Operation
Main Display
RCD AUTO Other
Menu Display
F1 Button
Pop-up and shutdown RCD menu , Shutdown mode is activated when the user
selects.
F2 Button
Pop-up and shutdown Trip Current menu , Shutdown mode is activated when
the user selects
F3 Button
Pop-up and shutdown Type of RCD menu , Shutdown mode is activated when
the user selects
F4 Button
Pop-up and shutdown Type of 0°/180° menu , Shutdown mode is activated
when the user selects
Up Button
Up menu to select the current active sub-options.
Down Button
Down menu to select the current active sub-options.
Enter Button
Confirm the user select mode.
-79-
