P350 Operation Manual 6
1.3 Crawlers and Cameras
The system offers two crawlers: the P354 (100mm/4” minimum pipe diameter) and P356 (150mm/6” minimum pipe
diameter). Both crawlers are compatible with a choice of three cameras. The P350-CAM-FW is a fixed, forward view
camera. The P350-CAM-PT offers pan and tilt and the P350-CAM-PTZ offers pan, tilt and 10x optical zoom.
P350 systems offer automatic TILT protection. By default, this will halt the crawler in hazardous tilting situations, when
its roll first exceeds 35°.The user will be shown a tilt hazard warning, and can restart the crawler movement if
necessary. The user can change this behavior to warn only, without stopping the crawler, or can disable the warning
altogether.
1.4 Pushrod reels and cameras
The P350 is compatible with the full range of P340
flexiprobe pushrod systems. The pushrod can be
directly connected to the command module, or to the
PSU.
In the MENU > SETUP > EQUIPMENT section,
pushrod mode is selected in the below menu. The
system will auto-detect whether the pushrod is
connected directly or to the drum PSU. This also
affects counter accuracy and video quality.
For information on assembling and using a pushrod
system, refer to the P340 flexiprobe user
documentation available at www.pearpoint.com.
Please note that a P340 Command module cannot
control a P350 crawler system.
