P350 flexitrax Operation Manual 53
Focus
You can manually adjust the focus of P350 FW and PT cameras. Press FN and or .
The P350-CAM-PTZ camera features automatic focus. You can adjust the focus manually pressing FN and or
. To resume automatic focus mode press FN, and simultaneously.
NOTE: the P350-CAM-FW and P350-CAM-PT have a focus range of 10mm (½") to infinity. The P350-CAM- PTZ has
a focus range of 10mm (½") (WIDE) to infinity.
Pan
When using the P350-CAM-FW camera you can use the pan function to digitally pan a zoomed-in picture on screen.
 To pan left or right, press Fn and or once to pan a fixed step in that direction.
 Press simultaneously Fn, and to reset the digital pan. When using the P350-CAM-PT and P350-CAM-
PTZ cameras you can pan from side to side, giving a wide field of vision without having to maneuver the whole
crawler.
 To pan left or right, press Fn and or once to start panning in that direction. Press either key again to
stop the camera panning.
Alternatively, use the gamepad controls. This uses the right-hand joystick and are direct control in the direction of
movement.
Tilt or rotate.
When using the P350-CAM-FW camera you can use the rotate function to digitally rotate the picture on screen.
 Press or to digitally rotate the picture clockwise or anti-clockwise
 Press the above simultaneously to reset the digital rotate.
The P350-CAM-PT and P350-CAM-PTZ cameras can rotate. When combined with the pan function, you can survey
objects above and below the crawler.
 To tilt/rotate the video on-screen clockwise press .
 To tilt/rotate the video on-screen anti-clockwise press .
 To stop rotating, press either key again.
Center
Press & together to reset the camera to the original central position.
Zoom
The P350-CAM-PTZ camera features a 10x optical zoom.
 To zoom in on the camera’s subject, press .
 To zoom out from the camera’s subject, press .
To reset the zoom, press the two buttons above simultaneously.
4.8 Digital Image effects (Pan, Tilt & Zoom)
Digital pan, tilt and zoom features are provided for use with forward view and pushrod cameras. Use the camera
controls as if for the equivalent camera and the system will automatically perform equivalent digital operations.
Digital pan, tilt and zoom features can also be used on video playback.
