P350 Operation Manual 88
Elevators
Elevators
P350-ELV-F-MK2
(Fixed Elevator)
P350-ELV-A
(Adjustable Elevator)
P350-ELV-LAM
(Large Manual Elevator)
P350-ELV-P
(Powered elevator)
Weight
0.7kg / 1.5lbs
0.7kg / 1.5lbs
4.5kg / 9.9lbs
6.5 kg / 14.3lbs
Construction
Stainless Steel and
Aluminum
Stainless Steel
Stainless Steel and
Aluminum
Stainless Steel and
Aluminum
Pipe Range
(P354)
Up to 300mm / 12”
Up to 380mm / 15”
Not available
Not available
Pipe Range
(P356)
up to 380mm / 15”
up to 458mm / 18”
300mm to 600mm
12” to 24”
300mm to 900mm
12” to 36”
Pendant Controller
Pendant Controller
P350-PENDANT
Dimension (L x Diameter)
250 x 80 x 40mm / 9.8” x 3.1” x 1.6”
Weight
0.7kg / 1.5lbs
Construction
Linear Medium Density Polyethylene (LMDPE) and mild steel
IP Rating
IP64
Product Approvals
Safety:
• EN 61010-1
• IEC 61010-1
• UL 61010-1
EMC:
• EN 61326-2-1 (Class A Emissions / Basic Immunity)
