Pentax K-3 User Manual

1
Introduction
12
You can change the type of information displayed in standby
mode by pressing G while the control panel is displayed. Use
CD to select the type and press E.
When shooting with the viewfinder
When shooting with Live View
The captured image and shooting information are displayed in
single image display of the playback mode.
Press G to change the type of information displayed in single
image display. Use CD to select the type and press E.
t Memo
• The display selected in Playback Info Display selection screen appears in
playback mode when the camera is turned off and on again. If [Playback Info
Display] is set to [Off] in [Memory] of the
A 4 menu, the [Standard Information
Display] always appears first when the camera is turned on. (p.75)
Shooting Info Display
Status
Screen
Displays the settings for shooting with the
viewfinder. (p.10)
Electronic
Level
Displays the camera
angle.
A bar scale indicating
the horizontal camera
angle appears at the
bottom of the screen,
and a bar scale
indicating the vertical
camera angle appears
on the right side. If the camera angle cannot be
detected, both ends and the center of the bar
scales flash red.
Display Off Nothing is displayed on the monitor.
Electronic
Compass
The current latitude, longitude, altitude,
direction, and Coordinated Universal Time
(UTC) are displayed. Turn the camera off and on
again to return to the status screen.
Available only when the optional GPS unit is
attached to the camera and is operating. (p.85)
Standard
Information
Display
The Live View image and the settings for
shooting with Live View are displayed. (p.10)
No
Information
Display
Certain icons, such as those for the Exposure
Mode and Drive Mode, are not displayed.
Example:
Tilted 1.5° to the left (yellow)
Vertically level (green)
When the camera is held vertically
When the camera is rotated to the vertical
position, the status screen and control
panel are displayed in a vertical position.
To not display images in the vertical
position, set [Auto Screen Rotation] to
[Off] in [LCD Display] of the D1 menu.
(p.22)
Playback Mode
Standard
Information Display
Captured image, file format, exposure value,
and operation guide indicators are displayed.
Detailed
Information Display
Detailed information on how and when the
image was taken is displayed (p.13).
Histogram Display
Captured image and brightness histogram are displayed (p.13).
Not available during movie playback.
RGB Histogram
Display
Captured image and RGB histogram are displayed (p.13).
Not available during movie playback.
No Information
Display
Only the captured image is displayed.
12 34 5
12345
12 34 5
12345
1/
1/
F
F
250
250
160 0
1600
5.6
5.6
1/
2000
1/
2000 F2.8F2.8 200200 +0.3+0.3
100-0001100-0001
1/
2000
1/
2000 F2.8F2.8 200200 +0.3+0.3
100-0001100-0001
Standa rd Inf ormati on Dis playStandard Information Display
Single image display
(Standard Information Display)
Playback Info Display
selection screen

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
