6
Appendix
81
All exposure modes are available when DA, DA L, or FA J lens
is used, or when a lens with an 9 position is used with the
aperture ring set to the 9 position.
When they are used in a position other than 9, or other lenses
are used, the following restrictions apply.
x: Available #: Restricted ×: Not available
*1 Lenses with a maximum aperture of F2.8 or faster. Only available at
the 9 position.
*2 Lenses with a maximum aperture of F5.6 or faster.
*3 Available when using the built-in flash, AF540FGZ, AF540FGZ II,
AF360FGZ, AF360FGZ II, AF200FG or AF160FC.
*4 Only available with compatible lenses.
*5 Distortion Correction and Peripheral Illumination Correction are
disabled when a DA FISH-EYE 10-17mm lens is used.
*6 To use an FA SOFT 28mm F2.8 lens, FA SOFT 85mm F2.8 lens, or
F SOFT 85mm F2.8 lens, set [27. Using Aperture Ring] to [Enable] in
the E4 menu. Pictures can be taken with the aperture you set, but
only within a manual aperture range.
*7 Only available with an FA 31mm F1.8 Limited, FA 43mm F1.9
Limited, or FA 77mm F1.8 Limited lens.
*8 Fixed to [Spot].
*9 J with the aperture open. (The aperture ring has no effect on the
actual aperture value.)
u Caution
• When the aperture ring is set to a position other than 9 or a
lens without an 9 position or accessories such as an auto
extension tube or auto bellows are used, the camera will not
operate unless [27. Using Aperture Ring] is set to [Enable] in
the E4 menu. Refer to “Using the Aperture Ring” (p.83) for
details.
Functions Available with Various
Lenses
Lens
[Mount type]
Function
DA
DA L
D FA
FA J
FA
*6
F
*6
A M
P
[KAF]
[KAF2]
[KAF3]
[KAF]
[KAF2]
[KAF] [KA] [K]
Autofocus
(Lens only)
(With AF adapter 1.7x)
*1
x
–
x
–
x
–
–
#
–
#
Manual focus
(With focus indicator)
*2
(With matte field)
xxxxx
Quick-shift focus #
*4
××××
Focus point selection mode
[Auto]
xxx #
*8
×
AE Metering [Multi-segment] xxxx
×
G/H/I/J/K mode xxxx #
*9
L mode xxxx #
P-TTL auto flash
*3
xxxx
×
Power zoom –
×
–––
Automatically obtaining the
lens focal length information
xxx
××
Lens Correction x
*5
×
*7
×××
Lens names and mount names
DA lenses with a motor and FA zoom lenses with power
zoom use the K
AF2 mount. DA lenses with a motor and no AF
coupler use the K
AF3 mount.
FA single focal length lenses (non-zoom lenses), DA or DA
L lenses without a motor, and D FA, FA J and F lenses use
the K
AF mount.
Refer to respective lens manuals for details.

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
