Pentax K-3 User Manual

3
Shooting
52
In C mode, you can use [Interval Movie Record] to take still
pictures at a set interval from a set time and save them as a
single movie file (Motion JPEG, file extension: .AVI).
1 Turn the Stills/Movie switch to C and press A.
The Drive Mode screen appears.
2 Select Y and press B.
3 Set the shooting
conditions.
4 Press E to finish the setting.
The camera returns to standby mode.
5 Press the shutter release button to start
shooting.
When [Start Interval] is set to [Now], the first picture is taken.
Instant Review is displayed, and then the monitor turns off.
After the set number of pictures are taken, the camera
returns to standby mode.
t Memo
• The shortest interval time that can be set for [Interval] is 10
seconds for [Digital Filter] and 20 seconds for [HDR Capture].
1 Press C in standby mode.
The White Balance setting screen appears.
2 Select the White Balance.
Available operations when shooting with the
viewfinder
Proceed to Step 5 if you do not need to change the
parameters.
Interval Movie Record
Recorded
Pixels
Select from z, u, or t.
Interval
Select from 2 sec., 5 sec., 10 sec., 20 sec., 30
sec., 1min., 5 min., 10 min., 30 min., or 1 hour.
Recording
Time
Set the time from the start to the end of recording.
Select from 14 seconds to 99 hours. The time that
can be set varies depending on the [Interval] setting.
Start
Interval
Select whether to take the first picture now or
at a set time.
When [Set Time] is selected, set the time at
which to start shooting in [Start Time].
2sec.
2sec.
Cancel
Cancel
OK
OK
Interv al
Interval
Record ed Pix els
Recorded Pixels
Interv al Mov ie Reco rd
Interval Movie Record
Record ing Time
Recording Time
Start Interv al
Start Interval
00 : 00 ' 14"
00: 00' 14"
Now
Now
Setting the White Balance
Y
g
g Auto White Balance
u Multi Auto White Balance
h Daylight
i Shade
j Cloudy
k
q Fluorescent - Daylight Color
r Fluorescent - Daylight White
s Fluorescent - Cool White
t Fluorescent - Warm White
l Tungsten
m Flash
n Color Temperature Enhancement
o Manual White Balance 1 to 3
p Color Temperature 1 to 3
Main switch to U Uses Digital Preview to preview
the background image with the
white balance effect applied.
H
Saves the preview image (only
when the data is available).
Auto W hite B alance
Auto White Balance
Cancel
Cancel
Check
Check
WB ±
WB ±
OK
OK

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
