Pentax K-3 User Manual

6
Appendix
82
Depending on the lens being used, the use of the built-in flash
may be limited.
The Shake Reduction function operates by obtaining the lens
information such as focal length. Set the focal length when
using a lens of which the focal length information cannot be
automatically obtained.
1 Turn the camera off.
2 Attach a lens to the camera and turn the camera
on.
The [Input Focal Length] screen appears.
3 Use AB to set the focal
length.
Press C to select a value from
the list.
When using a zoom lens, select
the actual focal length which the
zoom is set to.
4 Press E.
The camera returns to standby mode.
t Memo
• The focal length setting can be changed in [Input Focal
Length] of the A3 menu.
• When using a lens without an 9 position or a lens with an 9
position with the aperture ring set to a position other than 9,
set [27. Using Aperture Ring] to [Enable] in the E4 menu.
(p.83)
Compatibility with the Built-in Flash
Lens
Restrictions when using the
built-in flash
DA FISH-EYE 10-17mm
F3.5-4.5 ED (IF)/
DA 12-24mm F4 ED AL/
DA 14mm F2.8 ED (IF)/
FA
k
300mm F2.8 ED (IF)/
DA
k
560mm F5.6 ED AW/
FA
k
600mm F4 ED (IF)/
FA
k
250-600mm F5.6 ED
(IF)
The built-in flash is not available
due to vignetting.
F FISH-EYE 17-28mm
F3.5-4.5
Vignetting may occur if the focal
length is less than 20 mm.
DA 16-45mm F4 ED AL
When the focal length is less than
28 mm, or when the focal length
is 28 mm and the shooting
distance is 1 m or less, vignetting
may occur.
DA
k
16-50mm F2.8 ED
AL (IF) SDM
When the focal length is 20 mm
or less or when the focal length is
35 mm and the shooting distance
is less than 1.5 m, vignetting may
occur.
DA 17-70mm F4 AL (IF)
SDM
When the focal length is less than
24 mm or when the focal length is
35 mm and the shooting distance
is 1 m or less, vignetting may
occur.
DA 18-250mm F3.5-6.3
ED AL (IF)
Vignetting may occur if the focal
length is less than 35 mm.
DA 18-270mm F3.5-6.3
ED SDM
Vignetting may occur if the focal
length is less than 24mm.
FA
k
28-70mm F2.8 AL
Vignetting may occur if the focal
length is 28 mm and the shooting
distance is less than 1 m.
FA SOFT 28mm F2.8/
FA SOFT 85mm F2.8
The built-in flash always
discharges fully.
Setting the Focal Length
A3
Lens
Restrictions when using the
built-in flash
Input Focal Length
Input Focal Length
OK
OK
35
35
mm
mm

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
