Pentax K-3 User Manual

1
Introduction
14
When shooting with the viewfinder, the following information
appears in the viewfinder.
t Memo
• The information is displayed in the viewfinder when the
shutter release button is pressed halfway, or during the meter
operating time (default setting: 10 sec.).
• The AF point in use for autofocus appears in red
(Superimpose AF Area) when the shutter release button is
pressed halfway. You can set it to [Off] in [14. Superimpose
AF Area] of the E2 menu.
• You can adjust the diopter in the
viewfinder using the diopter
adjustment dial. Adjust the dial until
the AF frame in the viewfinder is
focused.
9 Aperture value 12 Histogram (R)
10 Sensitivity 13 Histogram (G)
11 EV Compensation 14 Histogram (B)
Viewfinder
1 AF frame (p.32) 11 Sensitivity (p.39)/
Exposure compensation
value
2 Spot metering frame
(p.40)
3 AF point (p.44) 12 AE Lock
4 Flash indicator (p.41) 13 Change AF Point (p.44)
5 Focus Method (p.42) 14 Multi-exposure (p.50)
6 Shutter speed 15 AE Metering (p.40)
7 Aperture value 16 Shake Reduction
8 Focus indicator 17 Flash Exposure
Compensation (p.41)
9 EV bar scale/Electronic
Level (p.15) 18 EV Compensation
(p.37)/Exposure
Bracketing (p.49)
10 ISO/ISO AUTO
19 File Format (p.35)
1
4
19
181716151413
61011
12
2
1
3
5 7 8 9

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
