6
Appendix
88
Error Messages
Error Messages Description
Memory card full
The memory card is full and no more
images can be saved. Insert a new
memory card or delete unwanted files.
No image
There are no images that can be played
back on the memory card.
This image cannot be
displayed
You are trying to play back an image in a
format not supported by this camera. You
may be able to play it back on a computer.
No card in the camera
There is no memory card inserted in the
camera.
Memory card error
The memory card has a problem, and
image capture and playback are
impossible. You may be able to play it
back on a computer.
Failed to initialize the Eye-Fi function
when using the Eye-Fi card. Press E.
Card is not formatted
The memory card you have inserted is
unformatted or has been previously used
on another device and is not compatible
with this camera. Use the card after
formatting it with this camera.
Card is locked
The write-protect switch on the memory
card you have inserted is locked. (p.102)
This image cannot be
magnified
You are trying to magnify an image that
cannot be magnified.
This image is protected
You are trying to delete an image that is
protected. Remove protection from the
image. (p.75)
Not enough battery
power remaining to
activate Pixel Mapping
Appears during Pixel Mapping, Sensor
Cleaning, or when trying to update the
firmware if the battery level is insufficient.
Install a fully charged battery.
Not enough battery
power remaining to
clean sensor
Not enough battery
power remaining to
update the firmware
Unable to update firmware.
There is a problem with the
firmware update file
Unable to update the firmware. The
update file is damaged. Try downloading
the update file again.
Image folder cannot be
created
The maximum folder number (999) is
being used, and no more images can be
saved. Insert a new memory card or
format the card.
Unable to store image
The image could not be saved because of
a memory card error.
The operation could not be
completed correctly
The camera was unable to adjust the
manual white balance. Try the operation
again.
No more images
can be selected
You are trying to select more than the
maximum number of images for the
following functions.
Select & Delete
Image Copy
Index
RAW Development
•Protect
Eye-Fi Image Transfer
No image can be processed
There are no images that can be
processed using the Digital Filter or RAW
Development function.
This image cannot be
processed
Appears when you try to perform Resize,
Cropping, Digital Filter, Movie Edit, RAW
Development, or Save as Manual WB for
images captured with other cameras, or
when you try to perform Resize or
Cropping for minimum file size images.
The camera failed
to create an image
The creation of an index print image
failed.
Error Messages Description

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax K-3 and is the answer not in the manual?

Pentax K-3 Specifications

General IconGeneral
Megapixel24.35 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels24.71 MP
Image sensor size- \
Image formats supportedJPG, RAW
Maximum image resolution6016 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)Jpeg – L (24M:6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M:6016x4000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax KAF2
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points27
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 51200, Auto
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash sync-speed1/180 s
Flash range (wide)- m
Shoe mounting point typeHot shoe
Video formats supportedAVC, AVI, H.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory- MB
Compatible memory cardsEye-Fi, FLU, SD, SDHC, SDXC
Display diagonal3.2 \
Vari-angle LCD displayNo
Display resolution (numeric)1037000 pixels
Magnification0.95 x
Viewfinder typeOptical
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorMicro-USB B
HDMI connector typeMicro
Data networkNot supported
Scene modesPortrait, Landscape (scenery)
Image editingCrop, Resizing, Rotating
Photo effectsBlack&White, Sepia
White balanceAuto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modesAperture priority, Manual, Sensitivity priority, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 12 s
Languages supportCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3
Diopter adjustment (D-D)-2.5 - 1.5
Power source typeBattery
Battery typeD-LI90
Battery life (CIPA standard)720 shots
MaterialMagnesium, Metal
Product colorBlack
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth77.5 mm
Width131.5 mm
Height102.5 mm
Weight715 g
Weight (including battery)800 g
