Pentax K-3 User Manual

1
Introduction
22
Set-up Menu
Menu Item Function Default Setting Page
D1
Language/W Changes the display language. English p.29
Date Adjustment Sets the date and time or display format. 01/01/2013 p.30
World Time
Switches between the date and time display of your hometown
city and that of a specified city.
Hometown p.74
Text Size Sets whether to magnify the text size when selecting a menu. Standard p.30
Sound Effects
Switches the operation sound on/off and changes the volume for
In-focus, AE-L, Self-timer, Remote Control, Mirror Up, Change
AF Point, and the P button operation.
Volume 3/
All On
–
LCD
Display
Guide Display
Sets whether to display the operation guides when the exposure
mode is changed.
On p.32
Auto Screen
Rotation
Sets whether to display the status screen and control panel
vertically if the camera is held vertically.
On p.12
Display Color
Sets the display color of the status screen, menu cursor, and
control panel.
1 p.11
LCD Display Settings Adjusts the brightness, saturation and the color of the monitor. 0 –
D2
USB Connection Sets the USB connection mode when connecting to a computer. MSC p.64
HDMI Out
Sets the output format when connecting to an AV device with an
HDMI input terminal.
Auto p.63
Folder Name Sets the folder name in which images are stored. Date p.76
Create New Folder Creates a new folder on the memory card. – p.76
File Name Sets the file name assigned to the image. IMGP/_IMG p.77
File No.
Sequential
Numbering
Sets whether to continue the sequential numbering for the file
name when a new folder is created.
On
p.77
Reset File Number
Resets the file number setting, and returns to 0001 each time a
new folder is created.
–
Copyright Information
Sets the photographer and copyright information embedded in
Exif.
Off p.78
D3
Flicker Reduction Cuts down on screen flicker by setting the power frequency. 50Hz –
Auto Power Off
Sets the time until the camera turns off automatically if no
operations are made for a certain period of time.
1 min. p.29
Select Battery
Sets the camera action for when the optional battery grip is
attached to the camera.
Auto Select/
Auto-detect
p.27

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
