Pentax K-3 User Manual

2
Getting Started
33
1 Press K in Step 6 on p.32.
The Live View image is displayed
on the monitor.
2 Position the subject inside
the AF frame on the
monitor and press the
shutter release button
halfway.
The AF frame turns green and
you will hear a beep when the
subject comes into focus.
Available operations during Live View
Subsequent steps are the same as shooting with the
viewfinder.
t Memo
• You can use I to focus on the subject. (p.42)
• You can preview the image on the monitor and check the
depth of field before shooting. (p.46)
• You can set the operation and display settings during Instant
Review in [Instant Review] of the A4 menu (p.19). When
[Display Time] is set to [Hold], Instant Review will be
displayed until the next operation.
u Caution
• Some functions are not available in T mode. If you attempt
to use the functions that are not available, such as the direct
key operation, the message [This function is not available in
the current mode] appears.
Shooting with Live View
E Magnifies the image.
Use R to change the magnification (up to
10x).
Use ABCD to change the display area.
Press M to return the display area to the
center.
Press E to return to the actual size.
K Exits the Live View shooting.
1/
2000
1/
2000
F2.8
F2.8
1600
1600
12345
12345
AF frame

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
