Pentax K-3 User Manual

2
Getting Started
28
We recommend the use of the optional AC adapter kit K-AC132
when using the monitor for a long time or when connecting the
camera to a computer or AV device.
1 Make sure that the camera
is turned off, and open the
terminal cover.
2 Align the A marks on the
DC terminal of the AC
adapter and DC input
terminal of the camera, and
connect.
3 Connect the AC adapter to the AC plug cord, and
plug the cord into the power outlet.
u Caution
• Make sure the camera is turned off before connecting or
disconnecting the AC adapter.
• Make sure connections are secure between the terminals.
The memory card or data may be corrupted if the connection
to the power supply is lost while the card is being accessed.
• Be sure to read the manual of the AC adapter kit before using
the AC adapter.
The following memory cards can be used with this camera.
• SD Memory Card, SDHC Memory Card, and SDXC Memory
Card
• Eye-Fi card
• Flucard compatible with this camera
In this manual, they are referred to as memory cards.
1 Make sure that the camera is turned off.
2 Slide the card cover in the
direction of 1.
3 Insert the card all the way
into the memory card slot
with the memory card label
facing toward the monitor.
Insert the card in the SD2 slot to
use an Eye-Fi card or a Flucard.
Push the memory card in once to
remove.
Using the AC Adapter
Inserting a Memory Card
2
1

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
