Pentax K-3 User Manual

3
Shooting
38
1 Turn the Stills/Movie switch to C.
Live View is displayed.
2 Focus on the subject.
In v mode, press the shutter release button halfway.
3 Press a.
Movie recording starts.
In the upper left area of the
monitor, “REC” blinks and the
size of the file being recorded is
displayed.
4 Press a again.
Movie recording stops.
u Caution
• When recording a movie with sound, the camera operation
sounds are also recorded.
• When recording a movie with an image processing function
such as Digital Filter applied, the movie file may be saved with
some frames omitted.
• If the internal temperature of the camera becomes high
during recording, the recording may be terminated.
t Memo
• Recording can be started or stopped by pressing the shutter
release button fully.
• You can change the movie settings in the C 1 menu or from
the control panel. (p.21) When [Exposure Setting] is set to
J, K or L, you can set the exposure before shooting.
• When [Recording Sound Level] is set to [MANUAL], a bar
graph indicating the microphone volume level appears on the
left edge (both edges when a stereo microphone is
connected) of the monitor.
• You can record a movie continuously up to 4 GB or 25
minutes. When the memory card is full, recording stops.
Recording Movies
10'30"
10'30"
Sound
Recordable Time
Using a Microphone or
Headphones
You can record stereo sound by
connecting a commercially
available stereo microphone to
the microphone terminal on the
camera. Using an external
microphone can also help to
reduce the possibility of recording
camera operation sounds.
The following specifications are recommended for external
microphones.
If the external microphone is disconnected during recording,
no sound will be recorded.
You can record and play back movies while listening to the
sound by connecting commercially available headphones to
the headphone terminal.
Microphone terminal
Headphone terminal
Plug Stereo mini plug (ø3.5 mm)
Format Stereo electret condenser
Power
Plug-in Power Method (operating
voltage of 2.0 V or lower)
Impedance 2.2 kΩ

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
