Page #77 background imageLoading...
Page #77 background image
5
Settings
75
t Memo
Refer to “List of World Time Cities” (p.94) for cities that can be
selected as a hometown or destination.
Select [F Hometown] in Step 3 to change the city and DST
settings for the hometown.
G appears in the control panel when [Time Setting] is set to
G.
Most of the functions set on this camera are saved even if the
camera is turned off. For the following function settings, you can
select whether to save the settings (T) or to return the settings
to their default values (S) when the camera is turned off. The
default settings are S for Digital Filter and HDR Capture, and
T for other functions.
Set in [Memory] of the A4 menu.
t Memo
When [Reset] of the D3 menu is performed, all Memory
settings return to the default values.
You can protect images from being accidentally deleted.
u Caution
Even protected images are deleted if the inserted memory
card is formatted.
1 Select Y in the playback mode palette.
The screen for selecting the unit for processing appears.
2 Select [Select image(s)] or
[Select a folder] and press
E.
3 Select the image(s) or folder to protect.
Refer to Step 2 of “Deleting Selected Images” (p.60) for how
to select the image(s) or a folder.
Proceed to Step 5 if [Select a folder] is selected.
4 Press G.
The confirmation screen appears.
5 Select [Protect] and press E.
t Memo
To protect all images stored in the memory card, select
[Protect All Images] of the B1 menu.
Selecting Settings to Save in the
Camera
A4
Flash Mode
Drive Mode
White Balance
Custom Image
Sensitivity
EV Compensation
Flash Exposure Compensation
Digital Filter
HDR Capture
Composition Adjust.
Playback Info Display
File Management Settings
Protecting Images from Deletion
(Protect)
Select a fol der
Select a folder
Select image (s)
Select image(s)
OK
OK

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax K-3 and is the answer not in the manual?

Pentax K-3 Specifications

General IconGeneral
Megapixel24.35 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels24.71 MP
Image sensor size- \
Image formats supportedJPG, RAW
Maximum image resolution6016 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)Jpeg – L (24M:6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M:6016x4000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax KAF2
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points27
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 51200, Auto
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash sync-speed1/180 s
Flash range (wide)- m
Shoe mounting point typeHot shoe
Video formats supportedAVC, AVI, H.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory- MB
Compatible memory cardsEye-Fi, FLU, SD, SDHC, SDXC
Display diagonal3.2 \
Vari-angle LCD displayNo
Display resolution (numeric)1037000 pixels
Magnification0.95 x
Viewfinder typeOptical
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorMicro-USB B
HDMI connector typeMicro
Data networkNot supported
Scene modesPortrait, Landscape (scenery)
Image editingCrop, Resizing, Rotating
Photo effectsBlack&White, Sepia
White balanceAuto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modesAperture priority, Manual, Sensitivity priority, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 12 s
Languages supportCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3
Diopter adjustment (D-D)-2.5 - 1.5
Power source typeBattery
Battery typeD-LI90
Battery life (CIPA standard)720 shots
MaterialMagnesium, Metal
Product colorBlack
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth77.5 mm
Width131.5 mm
Height102.5 mm
Weight715 g
Weight (including battery)800 g
