Pentax K-3 User Manual

6
Appendix
84
Using an optional external flash AF540FGZ, AF540FGZ II,
AF360FGZ, AF360FGZ II, AF200FG or AF160FC enables a
variety of flash modes, such as P-TTL auto flash mode.
x: Available #: Restricted ×: Not available
*1 Available only when using a DA, DA L, D FA, FA J, FA, F or A lens.
*2 Shutter speed of 1/90 seconds or slower.
*3 When combined with the AF540FGZ, AF540FGZ II, AF360FGZ, or
AF360FGZ II, 1/3 of the flash discharge can be output by the built-in
flash and 2/3 can be output by the external flash.
*4 Available only when combined with the AF540FGZ, AF540FGZ II,
AF360FGZ, or AF360FGZ II.
*5 Multiple AF540FGZ, AF540FGZ II, AF360FGZ, or AF360FGZ II units,
or a combination of an AF540FGZ, AF540FGZ II, AF360FGZ, or
AF360FGZ II unit and the built-in flash is required.
u Caution
• Never press the 1 button when any external flash unit is
attached to the camera. The built-in flash will hit the external
flash. If you want to use both at once, set the wireless mode
or connect them using an extension cord.
• Flashes with the reversed polarity (the center contact on the
hot shoe is minus) cannot be used due to the risk of damaging
the camera and/or flash.
• Do not combine with accessories that have a different
number of contacts, such as a Hot Shoe Grip, as a
malfunction may occur.
• Combining with flashes from other manufacturers may cause
equipment breakdown.
t Memo
• With the AF540FGZ, AF540FGZ II, AF360FGZ, or
AF360FGZ II, you can use the high-speed sync flash to
discharge the flash and take a picture at a shutter speed
faster than 1/180 seconds. Select an exposure mode (such
as I) which allows you to set the shutter speed.
• By using two external flashes (AF540FGZ, AF540FGZ II,
AF360FGZ, or AF360FGZ II) or using the built-in flash with
one or more external flashes, you can use the wireless mode
to shoot in P-TTL flash mode without connecting the flash
units with a cord. In this case, set the camera channel on the
external flashes. The set channel can be checked on the
status screen, Live View screen, LCD panel, and in the
viewfinder.
• You can connect an external flash
to the camera with a sync cord by
using the X-sync socket. Remove
the Sync socket 2P cap to connect
a sync cord to the X-sync socket.
Functions when Using an
External Flash
Flash
Camera Function
Built-in
Flash
AF540FGZ
AF540FGZ II
AF360FGZ
AF360FGZ II
AF200FG
AF160FC
Red-eye reduction flash xxx
Auto Flash Discharge xxx
Automatically switching to
the flash sync speed
xxx
Aperture value is
automatically set in G mode
and I mode.
xxx
P-TTL auto flash x
*1
x
*1
x
*1
Slow-speed Sync xxx
Flash Exposure
Compensation
xxx
AF assist light of external
flash
×
x
×
Trailing Curtain Sync
*2
xx
×
Contrast control sync flash
mode
#
*3
x #
*4
Slave flash
×
x
×
High-speed sync
×
x
×
Wireless flash #
*4
x
*5
×

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
