Pentax K-3 User Manual

4
Playback
59
Playback functions can be set in the
playback mode palette as well as the
B1 menu (p.21).
Press B in single image display of
the playback mode to display the
playback mode palette.
*1 Not available when a movie is displayed.
*2 Not available when a RAW image is displayed.
*3 Available only when a RAW image is saved.
*4 Available only when a movie is displayed.
*5 Available only when an Eye-Fi card is inserted in the SD2 slot.
t Memo
• The functions of the B1 menu and playback mode palette
can be used only for the images saved on the memory card
that is currently being played back. To use the functions for
the images saved on the other memory card, switch to the
other memory card slot with d during single image display,
then display the B1 menu or playback mode palette.
Playback Mode Palette Items
Item Function Page
S
Image Rotation
*1
Changes the rotation
information of images.
p.62
T Digital Filter
*1
Processes images with
digital filters.
p.66
h
Color Moiré
Correction
*1 *2
Reduces color moiré in
images.
p.66
V Resize
*1 *2
Changes the number of
recorded pixels or size of the
image.
p.65
W Cropping
*1
Crops out only the desired
area of an image.
p.65
X Index
Joins a number of images
together and creates an
index image with them.
p.68
Y Protect
Protects images from being
accidentally erased.
p.75
Z Slideshow
Plays back images one after
another.
p.62
o
Save as Manual
WB
*1
Saves the white balance
settings of the captured
image as Manual White
Balance.
p.53
a
Save Cross
Processing
Saves the settings used for
an image captured in Cross
Processing mode of Custom
Image as your “Favorite”
settings.
p.55
Image Rotati on
Image Rotation
Rotate s capt ured im ages.
Rotates captured images.
Useful for i mage pl ayback on
Useful for image playback on
TV and other displa y devi ces
TV and other display devices
Exit
Exit
OK
OK
b
RAW
Development
*3
Develops RAW images into
JPEG images and saves
them as a new file.
p.69
c Movie Edit
*4
Divides a movie or deletes
unwanted segments.
p.68
i Image Copy
Copies images between
cards in SD1 and SD2 slots.
p.65
e
Eye-Fi Image
Transfer
*1 *5
Transfers selected images
wirelessly using an optional
Eye-Fi card.
p.78
Item Function Page

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
