4
Playback
63
Connect to an AV device, such as a TV, equipped with an HDMI
terminal to display Live View images while shooting or to play
back images in playback mode.
Make sure to have a commercially available HDMI cable
equipped with an HDMI terminal (type D).
1 Turn the AV device and camera off.
2 Open the terminal cover of the camera, and
connect the cable to the HDMI terminal.
3 Connect the other end of the cable to the input
terminal on the AV device.
4 Turn the AV device and camera on.
The camera turns on in HDMI mode, and the camera
information is displayed on the screen of the connected AV
device.
u Caution
While the camera is connected to an AV device, nothing is
displayed on the camera monitor. Also, you cannot adjust the
volume on the camera. Adjust the volume on the AV device.
t Memo
Check the operating manual of the AV device and select a
suitable input terminal for connecting the camera.
If you intend to use the camera continuously for a long period,
use of the optional AC adapter kit is recommended.
By default, the maximum resolution corresponding to the AV
device and camera is automatically selected. If it fails to play
back images properly, change the setting in [HDMI Out] of the
D2 menu.
Connecting the Camera to an AV Device

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax K-3 and is the answer not in the manual?

Pentax K-3 Specifications

General IconGeneral
Megapixel24.35 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels24.71 MP
Image sensor size- \
Image formats supportedJPG, RAW
Maximum image resolution6016 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)Jpeg – L (24M:6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M:6016x4000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax KAF2
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points27
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 51200, Auto
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash sync-speed1/180 s
Flash range (wide)- m
Shoe mounting point typeHot shoe
Video formats supportedAVC, AVI, H.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory- MB
Compatible memory cardsEye-Fi, FLU, SD, SDHC, SDXC
Display diagonal3.2 \
Vari-angle LCD displayNo
Display resolution (numeric)1037000 pixels
Magnification0.95 x
Viewfinder typeOptical
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorMicro-USB B
HDMI connector typeMicro
Data networkNot supported
Scene modesPortrait, Landscape (scenery)
Image editingCrop, Resizing, Rotating
Photo effectsBlack&White, Sepia
White balanceAuto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modesAperture priority, Manual, Sensitivity priority, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 12 s
Languages supportCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3
Diopter adjustment (D-D)-2.5 - 1.5
Power source typeBattery
Battery typeD-LI90
Battery life (CIPA standard)720 shots
MaterialMagnesium, Metal
Product colorBlack
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth77.5 mm
Width131.5 mm
Height102.5 mm
Weight715 g
Weight (including battery)800 g
