Pentax K-3 User Manual

5
Settings
72
4 Press F.
The [Button Customization] screen reappears.
Repeat Steps 2 to 4.
5 Press F twice.
u Caution
• [LCD Panel Illumination] in [RAW/Fx Button] cannot be
selected when [22. LCD Panel Illumination] is set to [Off] in
the E4 menu.
1 Set [RAW/Fx Button] to [One Push File Format]
in Step 3 of “Setting the Button Operation”
(p.71).
2 Select T or S for [Cancel after 1 shot].
3 Select the file format when
P is pressed.
The left side is the [File Format]
setting and the right side is the
file format when P is pressed.
u Caution
• The One Push File Format function cannot be used when
[Memory Card Options] is set to [Separate RAW/JPEG] in the
A1 menu. (p.35)
AF
Button
Enable AF1
Autofocus is performed
when I is pressed.
p.42
Enable AF2
Autofocus is performed
when I is pressed and
not when the shutter
release button is
pressed halfway.
Cancel AF
While I is pressed,
autofocus is not
performed even when
the shutter release
button is pressed
halfway.
Preview
Dial
Optical
Preview
Activates the Optical
Preview.
p.46
Digital
Preview
Activates the Digital
Preview.
Setting Function Page
Setting the One Push File Format
T
The recording format returns to the [File Format]
setting of [Image Capture Settings] in the A1 menu
after a picture is taken. (Default setting)
S
The setting is retained until any of the following
operations is performed:
• When P is pressed again
• When B, F or G is pressed, or when the
mode dial or main switch is turned
One Pu sh Fil e Forma t
One Push File Format
RAW/F x Butt on
RAW/Fx Button
Cancel
Cancel
OK
OK
Cancel after 1 shot
Cancel after 1 shot

Pentax K-3 Specifications

General

Megapixel	24.35 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	24.71 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	Jpeg – L (24M：6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M：6016x4000)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	27
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 51200, Auto
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Flash sync-speed	1/180 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video formats supported	AVC, AVI, H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory	- MB
Compatible memory cards	Eye-Fi, FLU, SD, SDHC, SDXC
Display diagonal	3.2 \
Vari-angle LCD display	No
Display resolution (numeric)	1037000 pixels
Magnification	0.95 x
Viewfinder type	Optical
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	Micro-USB B
HDMI connector type	Micro
Data network	Not supported
Scene modes	Portrait, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modes	Aperture priority, Manual, Sensitivity priority, Shutter priority
Camera playback	Movie, Single image, Slide show
Self-timer delay	2, 12 s
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file system	DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-2.5 - 1.5
Power source type	Battery
Battery type	D-LI90
Battery life (CIPA standard)	720 shots
Material	Magnesium, Metal
Product color	Black
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	77.5 mm
Width	131.5 mm
Height	102.5 mm
Weight	715 g
Weight (including battery)	800 g
