5
Settings
79
u Caution
Be sure to insert an Eye-Fi card or a Flucard in the SD2 slot.
If it is inserted in the SD1 slot, the wireless LAN function
cannot be used. When an Eye-Fi card or a Flucard is not
inserted in the SD2 slot, the [Wireless Memory Card] settings
of the D3 menu cannot be set.
Be sure to set up a wireless LAN access point on a computer
for the card connection.
For RAW images and movie files, the success of transfer
depends on the specifications and settings of the Eye-Fi card
in use.
Images may not be transferred when the battery level is low.
It may take time to transfer a large number of images. The
camera may turn off if the internal temperature of the camera
becomes high.
For precautions on the Eye-Fi card, refer to “About Eye-Fi
Cards” (p.102).
t Memo
A smartphone can be used to operate this camera when a
Flucard compatible with this camera is used. Refer to the
Flucard manual for details on how to use the card.
When an Eye-Fi card is used, 100 images can be stored in a
single folder. For RAW+ images, two files are counted as one
image.
In Step 2, select [Communication Info] to check the Wireless
LAN information, and [Firmware Info/Options] to check the
firmware version of the cards.
When [Reset Transfer Settings] is selected in Step 2, the
[Action Mode] setting is returned to their default values.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax K-3 and is the answer not in the manual?

Pentax K-3 Specifications

General IconGeneral
Megapixel24.35 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerYes
Total megapixels24.71 MP
Image sensor size- \
Image formats supportedJPG, RAW
Maximum image resolution6016 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)Jpeg – L (24M:6016x4000), M (14M: 4608x3072), S (6M: 3072x2048), XS (2M: 1920x1280)\\r RAW – L (24M:6016x4000)
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfacePentax KAF2
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points27
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 51200, Auto
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed30 s
Flash sync-speed1/180 s
Flash range (wide)- m
Shoe mounting point typeHot shoe
Video formats supportedAVC, AVI, H.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Internal memory- MB
Compatible memory cardsEye-Fi, FLU, SD, SDHC, SDXC
Display diagonal3.2 \
Vari-angle LCD displayNo
Display resolution (numeric)1037000 pixels
Magnification0.95 x
Viewfinder typeOptical
USB version3.2 Gen 1 (3.1 Gen 1)
USB connectorMicro-USB B
HDMI connector typeMicro
Data networkNot supported
Scene modesPortrait, Landscape (scenery)
Image editingCrop, Resizing, Rotating
Photo effectsBlack&White, Sepia
White balanceAuto, Cloudy, Daylight, Flash, Fluorescent, Tungsten
Shooting modesAperture priority, Manual, Sensitivity priority, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 12 s
Languages supportCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Camera file systemDCF 2.0, Exif 2.3
Diopter adjustment (D-D)-2.5 - 1.5
Power source typeBattery
Battery typeD-LI90
Battery life (CIPA standard)720 shots
MaterialMagnesium, Metal
Product colorBlack
Operating temperature (T-T)-10 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth77.5 mm
Width131.5 mm
Height102.5 mm
Weight715 g
Weight (including battery)800 g
