48
27. [Confirmation] Function check 1
[Required equipment] Battery adaptor for 76830, DC code for 76830, Regulated DC power supply (8V/3A),
SD card, Circuit tester, Lens for checking (FA50mmF1.4), Battery grip D-BG2, Cable switch CS-205, remote
control F, Flash for checking (AF360FGZ etc)
27-1. Preparation
① Install Bottom cover and battery cover. (not need terminal cover for D-BG2)
27-2. Battery consumption
[Caution]If there is over current, disconnect the power immediately.
① Connect battery adaptor to the power supply and then set DC 5.6V (3A). (Set battery adaptor SW to
battery)
② Set the battery adaptor to the camera and confirm the battery consumption current.
There must be neither short nor leakage.
③ Release once and turn OFF the power of body then confirm the battery consumption current.
④ Set the battery adaptor SW to Grip and confirm the same as above ② and ③.
⑤ Remove the battery adaptor and connect the DC code to the power supply then set DC8.3V.
⑥ When connect the DC code to the camera, there must be neither short nor leakage.
⑦ Release once and turn OFF the power of body then confirm the battery consumption current.
27-3. AF and SI check
① Attach the lens (A position) to the camera and set the AF_SW to AF.S.
② Check auto focus function while pressing the shutter release button halfway.
③ Confirm the display of SI (Superimpose) in the viewfinder.
27-4. Exposure mode and release function
① Attach the lens (A position) to the camera and set the AF_SW to MF
② Set the mode dial to P.
③ TV, AV value should be display on the LCD and viewfinder when press shutter button halfway.
④ TV,AV value should be changed when turning front and back side e-dial.
⑤ When green button is pressed, exposure mode should back to Hyper program mode.
⑥ Confirm the display on the LCD and viewfinder while changing the mode dial.
⑦ Attach cable switch to the camera, and then check the shutter release function.
⑧ Set remote control mode by Fn button, and check the release function using remote control.
At the same time, you will hear the beep.
(With default setting. If selected beep off on the main menu, camera won’t beep)
Consumption current（Average）
Battery power
(DC7.5V)
AC power
（DC8.3V）
Main SW/OFF *50µA 15mA
Main SW/ON --- Light metering OFF 300mA 320mA
Light metering ON 540mA 540mA
Auto power off condition 250µA 15mA
