40
21-4. Data initialization
[Caution] If execute this initialization, all EEPROM data will be initialized (Cleared)
① Install SD card (For data initialization) to the camera.
② Connect the AC adaptor. (Initialization will be started.
It takes approx 20 sec.)
[Caution] Do not turn OFF the power
③ When monitor display is turn off, (“WAIT…” → “COMPLETE…” →)
disconnect the AC adapter.
22. [Adjustment] SR adjustment- 1 (Unit adjustment)
[Caution-1] When replacing T100, T970 or C000, you must execute this adjustment.
[Caution-2] Execute the adjustment on the stable table and do not give vibration to the camera while
adjusting
[Required equipment] Programmed software for 76830 (for SR unit adjustment), SR adjustment stand
Computer (Windows 2000 or Xp, USB port as standard equipment), USB cable, AC adaptor (DC cord for
76830 and power supply DC8.3V)
22-1. Setting for computer
Copy the folder [76830 SR Operation Adjustment] to the PC
22-2. Preparation
SR adjustment stand
①Set the AF mode lever to [MF].
② Attach SR adjustment stand to the camera
③ Put the camera on the stable table with
lens downward.
④ If replace T100, confirm the CCD ID number.
22-3. Procedure for adjustment
① Start up the computer.
② Connect the camera to the computer via USB cable and connect the AC adapter (Power ON).
③ Confirm that the camera is recognized by computer. (Hot plug icon).
④ Click [
K10D SR Operation cs.exe] in the adjustment software folder
⑤ Adjustment screen will be displayed.
⑥ Click [Start] to execute the program
76830 SR Operation Adjustment
USB cord
DC cord
CCD ID No.
WAIT(1) Install SD
card (For data
initialization
To Next Page
