50
27-8. Check Aperture control and CCD
① Attaching the lens to the camera. Set the focus mode and Capture mode to MF and B.
② The aperture of lens must change similarly when the aperture value (Av) is set in opening, the
middle, and the minimum with the Av dial.
③ Detach the lens from camera, and depress the release button, and make the camera long exposure
condition. Confirm there is neither dust nor scratch on the CCD.
27-9. Confirm with attaching D-BG2
① Attach the D-BG2 and confirm each operation of battery grip.
27-10．Check SD card cover SW
① The camera will turn OFF when the SD card cover is opened during the camera is turned ON.
② When close the SD card cover and press release bottom half way, the power must be turned ON.
28.[Adjustment] Adjustment for SLR operation
[Caution- 1] When the T100 is replaced, should be follow this adjustment
[Caution- 2] When execute this adjustment, each setting will be initialized except custom function.
[Caution-3] If refraction type of shutter tester is not used, shutter speed will adjust section of
[31. Shutter speed adjustment by histogram]
[Required equipments]
Programmed software for 76830 (for SLR operation), PC (Windows2000/XP with USB port equipped)
USB cable , exclusive AC Adaptor (or DC cord for 76830), Light source for AE adjustment (LV6 /LV8 or
LV9 / LV12 /LV15 orLV16 / Can be used Shutter tester), Master lens (95901 D20 with Lens ID No),
Diaphragm set ring F8 (KA-0-1A), F5.6 diaphragm plate for Master lens, AF positioning jig (Square) for
27830, AF positioning jig (Cross) for 27250, HD driver (HD-M1.5)
AF chart for 2m x2 (Exclusive item), AF master lens for 2m, D-FA (FA) Macro 50mmF2.8,
FA (F) 35-80mm F4-5.6, Battery adaptor for 76830, Regulated DC power supply (8V・3A)
Refection type of shutter tester for digital SLR. (1/4000sec can be checked, refer to caution-3)
*The adjustment method is same as 76700 (K100D)
Followings are listed particular contents for K10D. Refer to the service manual of 76700.
28-1. Setting the computer
* Setting the computer and Set up the VB run time should be completed
Refer to the service manual of 76642.
28-2. Preparation
① Attach battery cover and bottom cover temporary. (no terminal cover)
② Set focus mode to [MF]
③ Set mode dial to [M]
④ Set SR lever to [OFF]
76830_SLR
To Next Page
