54
28-4. AF shift adjustment (Optional)
*If AF does not improve by AF focus adjustment and there is no other factor,
execute AF shift adjustment if necessary.
① Click
□ button as shown in fig.
② Input [AFS] by capital letter and press [Enter] key.
③
[afs] will be displayed on tool bar.
④ When click [afs] button, below AF shift screen will be displayed.
⑤ Move the cursor right or left to change the value of AF shift. (+: shift to front side, -: shift to back side)
⑥ Click [Input] to adjust. (Can not input more than ±100um)
28-5. Procedure for Ending the program soft
① Click “Cl”icon and disconnect the correspond with camera. (USB close)
[Confirm] [Unconnect] is displayed on USB IO.
*Finish the Program soft with the same procedure of K100D.
Unconnect
76830
Data of camera
Valu e for shift
To Next Page
