AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
Installation
26.9.2013
13
6. Installation
6.1 Dimensions
6.2 Connections
55
85
120
7
75
Warning!
Cover the top of the gateway when doing any drilling work above the unit. No particles,
especially metal chips, should be allowed to enter the housing, since this could cause a
short circuit.
Information!
Please refer to installation instruction for this device for detailed mounting information.
10
10
AWG 24 ... 12
0,2 ... 2,5 mm
2
0,2 ... 2,5 mm
2
