AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
The Modbus Address Table
26.9.2013
73
11.2 AS-i circuit 1 data
11.2.1 Permanent configuration data
11.2.2 Enhanced diagnostic
AS-i circuit 1
permanent configuration data
4x reference access data
4385 ... 4400 r/w permanent parameter (PP)
4401 ... 4464 r/w permanent configuration data (PCD)
4465 ... 4468 r/w list of projected slaves (LPS)
Tab. 11-50.
AS-i circuit 1
enhanced diagnostic
4x reference access data
4609 ... 4672 r/-
transmisson error counters
1
1. The transmission error counters and the LCS are reset each time they are read.
4673 ... 4676 r/-
list of corrupted slaves LCS
1
4677 ... 4680 r/w list of offline slaves LOS
4681 ... 4684 r/- delta list
Tab. 11-51.
