10.8 Advanced Diagnostics Object
class code: 103 (0x67)
1 instance for each AS-i circuit
Instance 1 equates to AS-i circuit 1
Instance 2 equates to AS-i circuit 2
Slave error counter:
attribute
ID
access
rule
name devicenet
data type
default
data value
100 (0x64) Get/Set LOS (List of offline slaves) ULINT
101 (0x65) Get error counter A ARRAY[32] of USINT
102 (0x66) Get error counter B ARRAY[32] of USINT
Tab. 10-25.
single and A slaves
Index error counter
1 slave 1/1A
2 slave 2/2A
3 slave 3/3A
……
31 slave 31/31A
Tab. 10-26.
B slaves
index error counter
1slave 1B
2slave 2B
3slave 3B
……
31 slave 31B
Tab. 10-27.
