26.9.2013
42
AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
10.2 Device Level Ring Object
Class Code: 71 (0x47)
number of instanzes: 1
instance attributes
Common Services
Attribute ID Access Rule Name Value
1 (0x01) get network topo-
logy
0 (linear), 1 (ring)
2 (0x02) get network status 0 (normal), 1 (ring fault)
10 (0x0E) get active supervi-
sor address
byte 0-3: ip-adress,
byte 4-9: mac-adress
12 (0x0C) get capability flags 1 (announce-based ring node)
Tab. 10-5.
Service Code Class Instance Service Name
1 (0x01) yes yes get attributes all
14 (0x0E) yes yes get attribute single
Tab. 10-6.
